Corona and SOHO EIT 30.4nm composite

This image was created by replacing the Moon obscured part of the Sun by SOHO EIT He II 30.4nm image. It is clearly visible that the lunar angular diameter is bigger than the solar one.
Click on the image or on the following reference to display the higher resolution image version (3.7 MB, PNG format).

Date11. 08. 1999
Time2nd contact 11:36:13 UT, 3rd contact 11:38:19 UT
SOHO EIT Image: 12:02:16 UT
PlaceTurkey, Harput
Coordinate39° 15' 02" E, 38° 42' 08" N, Alt. 1372m
ConditionsVery good. Altitude of the Sun 53° above horizon.
OpticsZeiss 200/3000mm
Resolution2.71 arc sec / pixel (higher resolution image version)
FilmKodak PPF 6431 slide film of 18×24cm format
ProcessingComposition of 3 images. Images were aligned by means of phase correlation technique (PhaseCorr 3.0) and then processed using Corona 3.0 software by means of adaptive kernel convolution. Composition with SOHO image and final processing done by ACC 6.0.
Image processing by Miloslav Druckmüller
ScannerCanoscan 9900F
SoftwarePhaseCorr 3.0, Corona 3.0, Sofo ACC 6.0
OrientationThe image must be rotated 0.3° anticlockwise to achieve the standard orientation i.e. North top, East left
Copyright© 1999 Vojtech Rušin, © 2004 Miloslav Druckmüller


Miloslav Druckmüller
Institute of Mathematics, Faculty of Mechanical Engineering
Brno University of Technology, Czech Republic
