Corona and SOHO EIT 30.4nm composite

This image was created by replacing the Moon obscured part of the Sun by SOHO EIT He II 30.4nm image. The Moon position corresponds the time of the second contact and therefore on the left side the lunar and solar limb are nearly identical. On the right side the difference between the lunar and solar one is clearly visible.

Click on the following reference to display the same image in the maximum quality (871 KB, PNG format).

Date04. 12. 2002
TimeSecond contact: 06:18:26 UT, third contact 06:19:34 UT
Eclipse duration 1 min 8 s
PlaceSouth Africa, Messina, High School Eric Louw
Coordinate30° 00' E, 22° 23' S, altitude approx. 1500 m
ConditionsGood, in the end of totality thin clouds
OpticsZeiss 10/1000 mm
Resolution6.37 arc sec / pixel (image on this Web page)
FilmFujicolor Reala 100
Processing16 different images was used for corona image creation. Images were aligned by means of phase correlation technique and then processed using Corona 3.0 software. Composing with SOHO EIT 30.4 nm He II image and final processing was done by ACC 6.0 image analyzer.
Image processing by Miloslav Druckmüller
ScannerNikon Super Coolscan 4000 ED (4000dpi, 16× multisample)
SoftwarePhaseCorr 3.0, Corona 3.0, Sofo ACC 6.0
NoteSOHO EIT He II 30.4nm image was taken at 06:22:36 UT (file name: efz20021204.062236)
OrientationImage must be rotated 6.4° clockwise to achieve standard orientation (N top, E left)
Copyright© 2002 ESA/NASA, © 2004 Vojtech Rušin, Miloslav Druckmüller




Miloslav Druckmüller
Institute of Mathematics, Faculty of Mechanical Engineering
Brno University of Technology, Czech Republic
