Corona from the airplane
The resulting image on this page proves that even in the age of spacecraft observations the idea of
airborne eclipse photography is not dead. The conditions in altitude over 10 km are very near to the
conditions in space, the movements of the airplane during exposures does not seem to be a critical
problem and therefore the only limiting factor is the optical quality of the airplane's window. The high
quantity of images (51 in this particular case) enabled to overcome even this limiting factor. The
image composed of 51 images has a very low amount of additive noise and it makes possible to compensate
the loss of contrast on high spatial frequencies caused by scratched thick window.
Click on the following reference to display the same
image in the maximum quality (653 KB, PNG format).
|
| Image | Ecl2003_fd_cor.jpg |
| Date | 23. 11. 2003 |
| Time | 2nd contact: 22:42:43 UT
3rd contact: 22:45:18 UT |
| Place | QANTAS Flight 2901 over Antarctica (B 747 - 400) |
| Coordinate | 2nd contact: 69° 49' 24'' S, 93° 09' 45'' E
3rd contact: 70° 08' 32'' S, 92° 50' 52'' E |
| Conditions | Images taken through the exit-door window (camera on tripod) |
| Optics | 5.6/35-350 mm set to 350 m |
| Camera | Canon EOS D60 digital camera (images in JPEG format) |
| Exposure | 1× 1/1250 s, 3× 1/1000 s, 2× 1/800 s, 3× 1/640 s, 6× 1/400 s, 3× 1/250 s 3× 1/200 s, 6× 1/125 s, 6× 1/80 s, 3× 1/30 s, 4× 1/20 s, 5× 1/15 s, 6× 1/5 s |
| Processing | Composition of 51 images. Images were aligned by means of phase correlation, composed in one image using a special program written only for this particular purpose and finally processed by means of Corona 3.0 and ACC 6.0 software.
Image processing by Miloslav Druckmüller |
| Software | PhaseCorr 3.0, JPEG Composer 1.0, Corona 3.0, Sofo ACC 6.0 |
| Orientation | The image is presented in the orientation as it was visible from the aircraft. The image must be rotated 174.5° anticlockwise to achieve the standard orientation i.e. North top, East left |
| Copyright | © 2003 David Finlay, © 2005 Miloslav Druckmüller |
|
Miloslav Druckmüller
Institute of Mathematics, Faculty of Mechanical Engineering
Brno University of Technology, Czech Republic
