Extremely enhanced detail

This extremely enhanced detail of this image shows an interesting structure above an active region on the eastern limb of the Sun. Note some very faint stars very near the Sun.
Click on the image or on the following reference to display the higher resolution image version (2.3 MB, PNG format).

Date11. 07. 2010
Time2nd contact 18:45:36 UT, 3rd contact 18:50:05 UT
Total eclipse duration 4 m 29 s
PlaceTatakoto Atoll, French Polynesia
CoordinateS 17° 20' 39.3'',   W 138° 27' 3.1'',  Alt. 6 m
ConditionsPartially clear, partially thin clouds
Optics(1) William Optics FLT 110 mm APO F/7.0 + field flattener, focal length 760 mm
(2) Rubinar 10/1000 mm
(3) GSO RC 8'', Ritchey-Chrétien F/8, 203 mm/1624 mm
Camera(1) Canon EOS 5D Mark II digital camera (ISO 100)
(2,3) Canon EOS 5D digital camera (ISO 100)
Exposure(1) 1/500 s - 8 s
(2) 1/125 s - 8 s
(3) 1/500 s - 2 s
ProcessingComposition of 120 eclipse images (26 (1), 33 (2) 61 (3)). Eclipse images calibrated by means of dark frames and flat-fields, aligned by means of phase correlation, composed by means of LDIC 5.0 software, processed using Corona 4.1 in order to visualize coronal structures. Final processing was done using ACC 6.1 software.
Image processing by Miloslav Druckmüller
SoftwareAstro D3F 2.0, PhaseCorr 6.0, MPA 1.0, LDIC 5.0, Corona 4.1, Sofo ACC 6.1
OrientationImage must be rotated 3.78° anti-clockwise to achieve standard orientation i.e. solar north up.
Copyright© 2010 Miloslav Druckmüller, Martin Dietzel, Shadia Habbal, Vojtech Rušin



Miloslav Druckmüller
Institute of Mathematics, Faculty of Mechanical Engineering
Brno University of Technology, Czech Republic
