Corona from Svalbard
This image is the composition of 29 eclipse images acquired by means of 800 mm lens and Nikon D810
camera. Even though the Sun was only about 11° above the horizon it was possible to visualize
not only the solar corona in good contrast and high resolution but even the lunar surface
surprisingly well. The position of the Moon represents the situation 8 seconds after the second contact.
The full resolution image may be found here.
Click on the image or on the following reference to display the
higher resolution image version (2.3 MB, PNG format).
|
Image | Tse_2015_Svalbard_800mm_Nikon_D810.jpg |
Date | 20. 03. 2015 |
Time | 2nd contact 10:10:40 UT, 3rd contact 10:13:08 UT |
Place | Svalbard, airport |
Coordinate | N 78° 14' 48.6'', E 15° 29' 21.3'', Alt. 15 m |
Conditions | Clear sky |
Optics | TS Photo Line Apochromatic Triplet D=115 mm, f = 800 mm with 2.5 inch flattener |
Camera | Nikon D810 |
Exposure | 1/1600 s - 4 s |
Processing | Composition of 29 eclipse images. Eclipse images calibrated by means of dark frames and flat-fields, aligned by means of phase correlation, composed by means of LDIC 5.0 software, processed using Corona 4.1 in order to visualize coronal structures. Final processing was done using ACC 6.1 software. Image processing by Miloslav Druckmüller |
Software | Astro D3F 2.0, PhaseCorr 6.0, LDIC 5.0, Corona 4.1, Sofo ACC 6.1 |
Orientation | Image must be rotated 25.75° anti-clockwise to achieve standard orientation i.e. solar north up. |
Copyright | © 2015 Miloslav Druckmüller, Shadia Habbal, Peter Aniol, Pavel Štarha |
|
Miloslav Druckmüller
Institute of Mathematics, Faculty of Mechanical Engineering
Brno University of Technology, Czech Republic
druckmuller@fme.vutbr.cz
|
