Corona up to 5 solar radii


Click on the image or on the following reference to display the higher resolution image version (6.6 MB, PNG format).

Date02. 07. 2019
Time2nd contact 20:38:55 UT, 3rd contact 20:41:23 UT
Placetop of a hill near Tres Cruses, Chile
CoordinateS 29° 26.8867',   W 70° 49.1358',  Alt. 1160 m
ConditionsClear sky, solar altitude 13.2° above horizon
OpticsTS Imaging Star 4.9/347 mm
CameraZWO ASI1600MM Pro
Exposure0.001 s - 1.024 s
ProcessingComposition of 128 eclipse images. Eclipse images were calibrated by means of dark frames and flat-fields, aligned by means of phase correlation, composed by means of LDIC 6.0 software, processed using Corona 6.0 in order to visualize coronal structures. Final processing was done using ACC 6.1 software.
Image processing by Miloslav Druckmüller
SoftwareAstro D3F 2.0, PhaseCorr 7.0, LDIC 6.0, Corona 6.0, Sofo ACC 6.1
NoteColor is taken from wide angle color images
OrientationImage must be rotated 4.58° anti-clockwise to achieve standard orientation i.e. solar North up.
Copyright© 2019 Miloslav Druckmüller, Peter Aniol
