Corona in white light and EUV
The part of the solar image which was during the total solar eclipse occulted by the Moon was replaced by SDO
AIA data acquired in EUV spectral range. 304 A, 171 A and 211 A images processed by means of PM-NAFE
algorithm acquired during the time of total solar eclipse were used. The full resolution version of this
image you may download
here.
Click on the image or on the following reference to display the
higher resolution image version (2.6 MB, PNG format).
|
| Image | Tse_2021_md_wl-pm-nafe-N_top.jpg |
| Date | 4. 12. 2021 |
| Time | 2nd contact 07:45:00 UT, 3rd contact 07:45:38 UT |
| Place | Union Glacier, Antarctica |
| Coordinate | S 79° 44.340', W 82° 44.195', Alt. 715 m |
| Conditions | Clear sky, Solar altitude at mid-eclipse 13.9° above horizon |
| Optics | Nikkor 80-400mm 1:4.5-5.6G ED VR (set to FL 400 mm, F5.6) |
| Camera | Nikon Z6 |
| Exposure | 1/400 s - 2 s, ISO 100 |
| Processing | Composition of 24 eclipse images. Eclipse images were calibrated by means of dark frames and flat-fields, aligned by means of phase correlation, composed by means of LDIC 6.0 software, processed using Corona 6.0 in order to visualize coronal structures. Final processing was done using ACC 6.1 software.
Image processing by Miloslav Druckmüller
Images acquired by Andreas Möller |
| Software | Astro D3F 2.0, PhaseCorr 7.0, LDIC 6.0, Corona 6.0, Sofo ACC 6.1 |
| Orientation | Image standard orientation i. e. solar North up |
| Copyright | © 2021 Miloslav Druckmüller, Andreas Möller, SDO AIA 304 A |
|
Miloslav Druckmüller
Institute of Mathematics, Faculty of Mechanical Engineering
Brno University of Technology, Czech Republic
