Corona up to 9 solar radii
This unique eclipse image shows a huge CME propagating through the solar corona. The full resolution version
of this image you may download here. This image is oriented
so that solar North is on the top. If you prefer the orientation as it was visible in the sky
download this image version.
Click on the image or on the following reference to display the
higher resolution image version (2.5 MB, PNG format).
|
Image | Tse_2021_md_400mm-N_top.jpg |
Date | 4. 12. 2021 |
Time | 2nd contact 07:45:00 UT, 3rd contact 07:45:38 UT |
Place | Union Glacier, Antarctica |
Coordinate | S 79° 44.340', W 82° 44.195', Alt. 715 m |
Conditions | Clear sky, Solar altitude at mid-eclipse 13.9° above horizon |
Optics | Nikkor 80-400mm 1:4.5-5.6G ED VR (set to FL 400 mm, F5.6) |
Camera | Nikon Z6 |
Exposure | 1/400 s - 2 s, ISO 100 |
Processing | Composition of 24 eclipse images. Eclipse images were calibrated by means of dark frames and flat-fields, aligned by means of phase correlation, composed by means of LDIC 6.0 software, processed using Corona 6.0 in order to visualize coronal structures. Final processing was done using ACC 6.1 software. Image processing by Miloslav Druckmüller Images acquired by Andreas Möller |
Software | Astro D3F 2.0, PhaseCorr 7.0, LDIC 6.0, Corona 6.0, Sofo ACC 6.1 |
Orientation | Image standard orientation i. e. solar North up |
Copyright | © 2021 Miloslav Druckmüller, Andreas Möller |
|
Miloslav Druckmüller
Institute of Mathematics, Faculty of Mechanical Engineering
Brno University of Technology, Czech Republic
druckmuller@fme.vutbr.cz
|
Page last update: 27.1.2022
|
|
