Baily's beads before the second contact
This image of Baily's beads shows the impressive view several seconds before the second contact. The
rainbow-colored ray of light is caused by the secondary mirror holder of the Newtonian telescope.
Click on the image or on the following reference to display the
higher resolution image version (993 KB, PNG format).
|
| Image | Tse1991rdd_bp1.png |
| Date | 11. 07. 1991 |
| Time | 2nd contact 18:48:23 UT, 3rd contact 18:54:52 UT
Total eclipse duration: 6 min 29 sec |
| Place | Todos Santos, Baja California, Mexico |
| Coordinate | W 110° 17', N 23° 29' |
| Conditions | Clear sky, altitude of the Sun above the horizon: 82° |
| Optics | 10 inch F6 Newton reflector |
| Camera | Hasselblad |
| Film | Fujicolor 100 (6 × 6 cm) |
| Processing | Composition of 10 images. Images were aligned by means of phase correlation technique and then processed using Corona 4.0 software. Final processing was done by means of ACC 6.0 image analyzer.
Image processing by Hana Druckmüllerová and Miloslav Druckmüller |
| Scanner | Epson Perfection V750 Pro (6400 dpi resolution, 4× scanned each image) |
| Software | PhaseCorr 4.0, FilmCMP 2.0, Corona 4.0, Sofo ACC 6.0 |
| Orientation | The image must be rotated 11.8° clockwise to achieve the standard orientation i.e. North top, East left |
| Copyright | ©1991 Ronald E. Royer, ©2007 Hana Druckmüllerová, Miloslav Druckmüller |
|
