Outer corona
Even if the total solar eclipse of 1995 October 24 was very short on the observing place, only 50
seconds, it was long enough to take sequence of eight images covering the solar corona from the very Moon's
edge up to seven solar radii. The new composing method enables to create exact image including the
shape of the Moon. The black object in the image center is not a black circle covering the part of
image blurred by Moons's motion but sharp image of the Moon taken with 1/15s exposure. This single
image was used for reconstruction of the nearest neighborhood of the Moon. The more distant parts of
solar corona were reconstructed using all eight images.
Click on the following reference to display the same
image in the maximum quality (911 KB, PNG format).
|
| Image | Se1995i_outcor2.jpg |
| Date | 24. 10. 1995 |
| Time | Second contact: 03:02:43 UT, third contact 03:03:33 UT
Total eclipse duration 50s |
| Place | India (Rajastan), Nim Ka Thana |
| Coordinate | N 27° 44', E 75° 48' |
| Conditions | Very good |
| Optics | 8/500mm lens |
| Resolution | 14.06 arc sec / pixel (image on this Web page) |
| Film | Kodak Ektachrome 100 Plus (5005 EPP), 24×36mm |
| Exposure | 1/30, 1/15, 1/8, 1/4, 1/2, 1, 2, 4 s |
| Processing | Composition of 8 images. Images were aligned by means of phase correlation technique and then processed using Corona 3.0 software by means of adaptive kernel convolution. Final processing done in ACC 6.0.
Image processing by Miloslav Druckmüller |
| Scanner | Nikon Super Coolscan 4000 ED (16x multisample, 4000 dpi) |
| Software | PhaseCorr 3.0, Corona 3.0, Sofo ACC 6.0 |
| Orientation | The image must be rotated 32° clockwise to achieve the standard orientation i.e. North top, East left |
| Copyright | © 1995 Vojtech Rušin © 2004 Miloslav Druckmüller |
|
