Corona and Earth-lit Moon
The perfect display of the lunar surface in the resulting image is probably beyond the abilities of
human vision. As far as I know, nobody he reported visual observing of details on the lunar surface
during eclipse.
Click on the image or on the following reference to display the
higher resolution image version (2.2 MB, PNG format).
|
Image | Tse2006em_mo1.png |
Date | 29. 03. 2006 |
Time | 2nd contact 10:38:09 UT, 3rd contact 10:42:03 UT Total eclipse duration 3 m 54 s |
Place | El Salloum (Egyptian Desert, near Libyan border) |
Coordinate | E 25° 9.833', N 31° 33.833' |
Conditions | Clear sky, Sun altitude above horizon 62° |
Optics | Astro-Physics EDL 90 with Nikon 1.6x Teleconverter, EFL approx. 750mm |
Camera | Nikon D70 digital camera (ISO 200) |
Exposure | 1/2000 s - 1/2 s |
Processing | Composition of 58 images. Eclipse images were extracted from NEF format using Iris 5.32, aligned by means of phase correlation, composed using of LDIC 4.0 software, processed using Corona 4.0 in order to visualize coronal structures. Final processing was done using ACC 6.0 software. Image processing by Miloslav Druckmüller and Hana Druckmüllerová |
Software | Iris 5.32, PhaseCorr 4.0, LDIC 4.0, Corona 4.0, Sofo ACC 6.0 |
Orientation | Image must be rotated 28.0 ° anticlockwise to achieve standard orientation i. e. North up. |
Copyright | © 2006 Massimiliano Lattanzi, Hana Druckmüllerová, Miloslav Druckmüller |
|
Miloslav Druckmüller
Institute of Mathematics, Faculty of Mechanical Engineering
Brno University of Technology, Czech Republic
druckmuller@fme.vutbr.cz
|
Page last update: 27.11.2019
|
|
