All corona visible from observing place

Composing of all images taken from the second to the third contact enables to create an image which shows all of the solar corona progressively visible from the particular observing place. The resulting image was made from 63 digital images taken with Maksutov-Cassegrain MC 3M-5CA, 8/500 mm and one image on a classical film taken with Rubinar (modified Maksutov-Cassegrain) 5.6/500 mm with 2× teleconverter (the 3rd contact image). The upper left part represents the image of the second contact, while the lower right part represents the third contact (see this image).

Click on the image or on the following reference to display the higher resolution image version (2.4 MB, PNG format).

Date29. 03. 2006
Time2nd contact 11:02:23 UT, 3rd contact 11:05:29 UT
Total eclipse duration 186 s
PlaceNear Göreme, Cappadocia, Turkey
CoordinateE 34° 52.147', N 38° 39.390', alt. 1330 m
ConditionsGood, thin cirrus clouds out of the solar disk, strong wind, altitude of the Sun above the horizon 50°
OpticsD: Maksutov-Cassegrain MC 3M-5CA, 8/500 mm
B: Rubinar 5.6/500 mm with Kinotelex 2× WMC teleconverter
CameraD: Canon EOS 1D Mark II digital camera (ISO 100)
B: Canon EOS 300 N classical film camera
FilmB: Fujicolor Superia X-TRA 800
ExposureD: 1/1000 s - 8 s
B: 1/500 s
ProcessingComposition of 63 images digital images (D) and one image taken on classical film (B). Eclipse images were aligned by means of phase correlation, composed using of LDIC 4.0 software, processed using Corona 4.0 in order to visualize coronal structures. Final processing was done using ACC 6.0 software.
Image processing by Miloslav Druckmüller and Hana Druckmüllerová
ScannerB: Nikon Super Coolscan 4000 ED (16× multisample)
SoftwarePhaseCorr 4.0, LDIC 4.0, Corona 4.0, Sofo ACC 6.0
NoteD denotes equipment of Hana Druckmüllerová
B denotes equipment of Eva Brandejsová
OrientationImage must be rotated 28.73° anti-clockwise to achieve standard orientation i. e. North up.
Copyright© 2006 Eva Brandejsová, Hana Druckmüllerová, Miloslav Druckmüller




Miloslav Druckmüller
Institute of Mathematics, Faculty of Mechanical Engineering
Brno University of Technology, Czech Republic
