Earth-lit Moon
This image is beyond the abilities of the human vision. As far as I know, nobody from the expedition saw any
detail on the Moon's surface.
The image is a complicated composition of totaly 63 images taken with F8 500 mm
Maksutov-Cassegrain. It was necessary to align separately the solar corona and separately the Moon.
The movement of the Moon relatively to the Sun in so fast that about 5 seconds difference in images
acquisition would cause noticeable blurring of the Moon. A good illustration of the movement is the
composed image showing the position of the Moon at the
second and at the third contact. Furthermore, the composed image makes evident that the observing place
was not on the central line.
Click on the image or on the following reference to display the
higher resolution image version (2.4 MB, PNG format).
|
Image | Tse2006tc_h500_in30_32mo.jpg |
Date | 29. 03. 2006 |
Time | 2nd contact 11:02:23 UT, 3rd contact 11:05:29 UT Total eclipse duration 186 s |
Place | Near Göreme, Cappadocia, Turkey |
Coordinate | E 34° 52.147', N 38° 39.390', alt. 1330 m |
Conditions | Good, thin cirrus clouds out of the solar disk, strong wind, altitude of the Sun above the horizon 50° |
Optics | Maksutov-Cassegrain MC 3M-5CA, 8/500 mm |
Camera | Canon EOS 1D Mark II (ISO 100) |
Exposure | 1/1000 s - 8 s |
Processing | Composition of 63 images. Eclipse images were aligned by means of phase correlation, composed using of LDIC 4.0 software, processed using Corona 4.0 in order to visualize coronal structures. Final processing was done using ACC 6.0 software. Image processing by Miloslav Druckmüller and Hana Druckmüllerová |
Software | PhaseCorr 4.0, LDIC 4.0, Corona 4.0, Sofo ACC 6.0 |
Orientation | Image must be rotated 28.73° anti-clockwise to achieve standard orientation i. e. North up. |
Copyright | © 2006 Hana Druckmüllerová, Miloslav Druckmüller |
|
Miloslav Druckmüller
Institute of Mathematics, Faculty of Mechanical Engineering
Brno University of Technology, Czech Republic
