High resolution image of inner corona
This high-resolution image shows not only the inner corona in the delicate details but surprisingly the
lunar surface is recorded in the quality not very far from an image taken during the full moon. Even
small craters are clearly visible on the lunar surface. It is
necessary to align the solar corona and the Moon separately in order not to blurr one of these two
parts.
Click on the image or on the following reference to display the
higher resolution image version (2.7 MB, PNG format).
|
| Image | Tse2008_1250_mo1.png |
| Date | 01. 08. 2008 |
| Time | 2nd contact 11:03:35 UT, 3rd contact 11:05:39 UT
Total eclipse duration 2 m 4 s |
| Place | Mongolia, Bor Udzuur |
| Coordinate | 45° 43.251' N, 92° 06.837' E, 1223 m altitude |
| Conditions | Excellent - clear sky, altitude of the Sun above the horizon 22° |
| Optics | 105mm TMB APO f=620mm + Baader Flat-field FFC EFL |
| Camera | Canon EOS 1Ds Mark III digital camera (ISO 100) |
| Exposure | 1/4000 s - 8 s |
| Processing | Composition of 25 images. Eclipse images were calibrated by means of several hundreds of dark frames and flat-fields, aligned by means of phase correlation, composed by means of LDIC 5.0 software, processed using Corona 4.1 in order to visualize coronal structures. Final processing was done using ACC 6.1 software.
Image processing by Miloslav Druckmüller |
| Software | Astro D3F 2.0, PhaseCorr 6.0, LDIC 5.0, Corona 4.1, Sofo ACC 6.1 |
| Orientation | Image must be rotated 12.1° clockwise to achieve standard orientation i. e. North up. |
| Copyright | © 2008 Miloslav Druckmüller, Martin Dietzel, Peter Aniol, Vojtech Rušin |
|
