Eclipse image composed with SOHO LASCO C3
The resulting wide-angle eclipse image visualizes the
corona with acceptable contrast up to nearly 20 solar radii. The next logical step was to compose the
Earth-based image with the SOHO LASCO C3 coronograph image. The bright points in the resulting images
are stars. The original image contains not only stars, but also impulse noise. This impulse noise
was filtered out. In order to preserve stars, it was necessary to identify them before the filtering
procedure. It was done by aligning and comparing two different SOHO images.
Click on the image or on the following reference to display the
higher resolution image version (553 KB, PNG format).
|
Image | Tse2008_200_c3.jpg |
Date | 01. 08. 2008 |
Time | 2nd contact 11:03:35 UT, 3rd contact 11:05:39 UT Total eclipse duration 2 m 4 s |
Place | Mongolia, Bor Udzuur |
Coordinate | 45° 43.251' N, 92° 06.837' E, 1223 m altitude |
Conditions | Excellent - clear sky, altitude of the Sun above the horizon 22° |
Optics | Canon 2.8/70-200 mm L set to 200 mm (Canon EOS 5D) Maksutov-Cassegarin 3M-6A, 6.3/500 mm (Canon EOS 350D) |
Camera | Canon EOS 5D (Hutech Ia modification) (ISO 100 and 200) Canon EOS 350D digital camera (ISO 100) |
Exposure | 1/125 s - 8 s |
Processing | Composition of 55 eclipse images (23 Canon EOS 5D, 22 Canon EOS 350D) and SOHO LASCO C3 image. Eclipse images calibrated by means of dark frames and flat-fields, aligned by means of phase correlation, composed by means of LDIC 5.0 software, processed using Corona 4.1 in order to visualize coronal structures. Final processing was done using ACC 6.1 software. Image processing by Miloslav Druckmüller |
Software | Astro D3F 2.0, LDIC 5.0, Corona 4.1, Sofo ACC 6.1 |
Note | SOHO C3 was image taken at 11:18 UT |
Orientation | Image has standard orientation i. e. North up. |
Copyright | © 2008 Miloslav Druckmüller, Peter Aniol, Vojtech Rušin |
|
Miloslav Druckmüller
Institute of Mathematics, Faculty of Mechanical Engineering
Brno University of Technology, Czech Republic
