Corona up to 3.5 solar radii
The raw input data used for creation of this image have 57.2 GB (1891 raw images - eclipse images,
dark frames and flat-fields before RGB matrix interpolation and RGB separation). The image presented
in this web page was made from data obtained by means of three different cameras with lenses from
760 mm to 1624 mm focal length (see the table below). It was necessary to combine data from all
these cameras because of rolling clouds. If the sky is clear, only one camera would be enough for creation
of image of this quality. But the sky during the totality was far from to be perfect. The
nearest neighborhood of the Sun was clear only for several rather short intervals. Fortunately even
these several dozens of second long intervals were enough because of the exposure sequence strategy
which was prepared for this eventuality. The main data set consists of images taken by means of
Rubinar 10/1000 mm and other two sets of images were aligned with this set using phase correlation
based on Fourier transform. The alignment was necessary between different cameras only, because the
tracking of the fantastic Astelco NTM 500 mount was in sub-arcsecond precision during the eclipse.
The stars are not round because the Sun is moving rather fast among the stars - about
1° per day. The star trails are of different length because every image part consists of
different images taken at different time. The trails of bright stars are usually longer because they
are recorded on more images than faint stars. The full resolution image is
here.
Click on the image or on the following reference to display the
higher resolution image version (2.4 MB, PNG format).
|
Image | Tse2010t_wrr1.jpg |
Date | 11. 07. 2010 |
Time | 2nd contact 18:45:36 UT, 3rd contact 18:50:05 UT Total eclipse duration 4 m 29 s |
Place | Tatakoto Atoll, French Polynesia |
Coordinate | S 17° 20' 39.3'', W 138° 27' 3.1'', Alt. 6 m |
Conditions | Partially clear, partially thin clouds |
Optics | (1) William Optics FLT 110 mm APO F/7.0 + field flattener, focal length 760 mm (2) Rubinar 10/1000 mm (3) GSO RC 8'', Ritchey-Chrétien F/8, 203 mm/1624 mm |
Camera | (1) Canon EOS 5D Mark II digital camera (ISO 100) (2,3) Canon EOS 5D digital camera (ISO 100) |
Exposure | (1) 1/500 s - 8 s (2) 1/125 s - 8 s (3) 1/500 s - 2 s |
Processing | Composition of 120 eclipse images (26 (1), 33 (2) 61 (3)). Eclipse images calibrated by means of dark frames and flat-fields, aligned by means of phase correlation, composed by means of LDIC 5.0 software, processed using Corona 4.1 in order to visualize coronal structures. Final processing was done using ACC 6.1 software. Image processing by Miloslav Druckmüller |
Software | Astro D3F 2.0, PhaseCorr 6.0, MPA 1.0, LDIC 5.0, Corona 4.1, Sofo ACC 6.1 |
Orientation | Image must be rotated 10.8° anti-clockwise to achieve standard orientation i.e. solar north up. |
Copyright | © 2010 Miloslav Druckmüller, Martin Dietzel, Shadia Habbal, Vojtech Rušin |
|
Miloslav Druckmüller
Institute of Mathematics, Faculty of Mechanical Engineering
Brno University of Technology, Czech Republic
