Baily's beads 2 seconds before C2
Single one image of Baily's beads was used for the brightest part of this image. The lower light
intensity the more images were used. Total number of used images is 52. Clouds are motion-blurred
because the images are aligned on solar corona
Click on the image or on the following reference to display the
higher resolution image version (1.6 MB, PNG format).
|
Image | Tse_2013_bp-13.jpg |
Date | 3. 11. 2013 |
Time | 2nd contact 14:24:46 UT, total eclipse duration 10 s (measured) |
Place | Kenya |
Coordinate | N 3° 29' 42.07", E 35° 26' 46.72", Alt. 565 m |
Conditions | Partially cloudy |
Optics | (1) MTO 10/1000 mm (2) 3M-5CA 8/500 mm (3) 3M-65CA 6.3/500 mm |
Camera | (1,2,3) Canon EOS 5D Mark II (ISO 100) |
Exposure | (1) 1/250 s, 1/60 s,1/15 s (2) 1/45 s, 1/15 s, 1/6 s (3) 1/4 s, 1/1.4 s, 2 s |
Processing | Composition of 52 eclipse images - 24 images (1), 22 images (2), 6 images (3). Digital eclipse images were calibrated by means of large number of dark frames and flat-fields, aligned by means of phase correlation, composed by means of LDIC 5.0 software, processed using Corona 4.1 in order to visualize coronal structures. Final processing was done using ACC 6.1 software. Image processing by Miloslav Druckmüller |
Software | Astro D3F 2.0, PhaseCorr 6.0, LDIC 6.0, Corona 4.1, Sofo ACC 6.1 |
Copyright | © 2013 Pavel Štarha, Kristián Molnár, Shadia Habbal © 2014 Miloslav Druckmüller |
|
