Wide-angle image from Sulawesi
|
This image is slightly influenced by a thin cloud which was moving from the top downwards the field
of view in the left part of the image.
|
| Image | TSE_2016_dd.png |
| Date | 09.03.2016 |
| Time | 2nd contact 00:39:58 UT, 3rd contact 00:42:49 UT, Duration 171 s |
| Place | Ampana, Central Sulawesi, Indonesia |
| Coordinate | S 0° 51.183', E 121° 36.017' |
| Conditions | Clear sky, partially very thin cloud |
| Optics | Tamron SP 70-300 mm F/4-5.6 Di (300 mm) |
| Camera | Canon EOS D60 |
| Exposure | 1/1000 s - 8 s |
| Processing | Composition of 34 eclipse images. Eclipse images were calibrated by means of dark frames and flat-fields, aligned by means of phase correlation, composed by means of LDIC 5.0 software, processed using Corona 4.1 in order to visualize coronal structures. Final processing was done using ACC 6.1 software.
Image processing by Miloslav Druckmüller |
| Software | Astro D3F 2.0, PhaseCorr 6.0, LDIC 5.0, Corona 4.1, Sofo ACC 6.1 |
| Copyright | © 2016 Mirek Dočekal, Miloslav Druckmüller |
|
