Wide-angle image from Sulawesi

This image is slightly influenced by a thin cloud which was moving from the top downwards the field of view in the left part of the image.
Click on the following reference to display the same image in the maximum quality (1.3 MB, PNG format).

Time2nd contact 00:39:58 UT, 3rd contact 00:42:49 UT, Duration 171 s
PlaceAmpana, Central Sulawesi, Indonesia
CoordinateS 0° 51.183',   E 121° 36.017'
ConditionsClear sky, partially very thin cloud
OpticsTamron SP 70-300 mm F/4-5.6 Di (300 mm)
CameraCanon EOS D60
Exposure1/1000 s - 8 s
ProcessingComposition of 34 eclipse images. Eclipse images were calibrated by means of dark frames and flat-fields, aligned by means of phase correlation, composed by means of LDIC 5.0 software, processed using Corona 4.1 in order to visualize coronal structures. Final processing was done using ACC 6.1 software.
Image processing by Miloslav Druckmüller
SoftwareAstro D3F 2.0, PhaseCorr 6.0, LDIC 5.0, Corona 4.1, Sofo ACC 6.1
Copyright© 2016 Mirek Dočekal, Miloslav Druckmüller

Miloslav Druckmüller
Institute of Mathematics, Faculty of Mechanical Engineering
Brno University of Technology, Czech Republic
Page last update: 3.5.2016
