Solar corona from Bangka Island
There are two versions of this image. The version with the Sun in the center and the second one showing
very prominent long streamer.
|
Image | TSE_2016_srd.png |
Date | 09.03.2016 |
Time | 2nd contact 00:22:11 UT, 3rd contact 00:24:03 UT, duration 112 s |
Place | Penyak Beach, Bangka Island, Indonesia |
Coordinate | S 2° 26.6983', E 106° 19.663' |
Conditions | Clear sky |
Optics | Astro-Tech AT111EDT apochromatic triplet refractor and a zero power 2" field flattener F7, 777 mm focal length |
Camera | modified Nikon D810 |
Exposure | 1/2000 s - 4 s |
Processing | Composition of 32 eclipse images. Eclipse images were calibrated by means of dark frames and flat-fields, aligned by means of phase correlation, composed by means of LDIC 5.0 software, processed using Corona 4.1 in order to visualize coronal structures. Final processing was done using ACC 6.1 software. Image processing by Miloslav Druckmüller |
Software | Astro D3F 2.0, PhaseCorr 6.0, LDIC 5.0, Corona 4.1, Sofo ACC 6.1 |
Copyright | © 2016 Don Sabers, Ron Royer, Miloslav Druckmüller |
|
Miloslav Druckmüller
Institute of Mathematics, Faculty of Mechanical Engineering
Brno University of Technology, Czech Republic
