Corona in white light and EUV

The innermost part of this total solar eclipse image was replaced by SDO AIA data acquired in EUV spectral range. 304 A, 171 A and 211 A images processed by means of NAFE algorithm acquired during the time of total solar eclipse were used.

The full resolution image you may see here.
Click on the image or on the following reference to display the higher resolution image version (4.7 MB, PNG format).

Date14. 12. 2020
Time2nd contact 16:07:59 UT, 3rd contact 16:10:04 UT
PlaceFortin Nogueira, Neuquen, Argentina
CoordinateS 39° 57.680',   W 69° 59.576',  Alt. 485 m
ConditionsClear sky for 85 s of totality otherwise thin clouds
Solar altitude at mid-eclipse 72.4° above horizon
OpticsNikkor 80-400mm 1:4.5-5.6G ED VR (set to FL 400 mm, F5.6)
CameraNikon Z6
Exposure1/640 s - 3 s, ISO 100
ProcessingComposition of 55 eclipse images. Eclipse images were calibrated by means of dark frames and flat-fields, aligned by means of phase correlation, composed by means of LDIC 6.0 software, processed using Corona 6.0 in order to visualize coronal structures. Final processing was done using ACC 6.1 software.
Image processing by Miloslav Druckmüller
Eclipse images acquired by Andreas Möller
SoftwareAstro D3F 2.0, PhaseCorr 7.0, LDIC 6.0, Corona 6.0, Sofo ACC 6.1
OrientationThis image has exact solar North on the top orientation
Copyright© 2020 Miloslav Druckmüller, Andreas Möller



Miloslav Druckmüller
Institute of Mathematics, Faculty of Mechanical Engineering
Brno University of Technology, Czech Republic
