Penumbral Phase of Total Lunar Eclipse on May 16, 2003
It is uneasy to record the subtle penumbral lunar eclipse. Small brightness and color differences of
the Moon can be easily lost by changing the film exposure, scanner setting or by improper image
processing. It is necessary to calibrate all images to achieve good results. The sequence of images
you are looking at was taken during the penumbral phase of total Lunar Eclipse on May 16, 2003. The
start of penumbral eclipse was at 03:07 local time (01:07 UT). Three minutes later was the first
picture of the sequence taken. The pictures follow in ten minutes time intervals. The last picture
was taken at 04:00 local time (02:00 UT), three minutes before the umbral shadow touched the Moon. It
is clearly visible that the penumbral shadow is of brown-orange color caused by the filtration of
sunlight illuminating the Moon by Earth's atmosphere. If you look at the right limb of the Moon which
is not influenced by penumbral shadow at the eclipse beginning you realize that the Moon as the whole
is changing its color little bit from neutral gray to brown. This effect is caused by decreasing the
Moon height above the horizon, i. e. again by filtration of the light by our atmosphere. In this case
it is the filtration of the moonlight - sunlight reflected by the Moon's surface. The last picture of
the sequence was taken about 80 minutes before the moonset.
Click on the image or on the following reference to display the
higher resolution image version (340 KB, PNG format).
|
Image | Ecll05162003_penumb.jpg |
Date | 16. 05. 2003 |
Time | From 01:10 UT to 02:00 UT in 10 min intervals |
Place | Stanovisko hill about 25 km far from Brno city, Czech Republic |
Conditions | Very good - clear sky, near horizon very thin fog |
Optics | GS 300, 10.8/1000 mm |
Camera | Minolta X-700 |
Film | Agfa Vista 200 |
Processing | Picture taken just before penumbral eclipse start was used for color calibration (Full Moon was defined as gray). The same calibration was used for following pictures. Image processing by Miloslav Druckmüller |
Scanner | Nikon LS 2000 (2750dpi resolution, RGB, 3 × 16bit/pixel, 4 × multisample) |
Software | Sofo ACC 5.0 Scientific Image Analyzer with Match II Module |
Copyright | © 2003 Miloslav Druckmüller |
|
Miloslav Druckmüller
Institute of Mathematics, Faculty of Mechanical Engineering
Brno University of Technology, Czech Republic
